DIMENSIONS :
| SPECIFICATION |
LXi/ LXi CNG |
VXi/ VXi AGS |
VXi+/ VXi+ AGS |
| LENGTH |
3599 mm |
3599 mm |
3636 mm |
| WIDTH |
1495 mm |
1495 mm |
1475 mm |
| HEIGHT |
1700 mm |
1700 mm |
1670 mm |
| WHEELBASE |
2400 mm |
2400 mm |
2400 mm |
| FRONT TREAD |
1295 mm |
1295 mm |
1295 mm |
| REAR TREAD |
1290 mm |
1290 mm |
1290 mm |
| MINIMUM GROUND CLEARANCE |
165 mm (UNLADEN CONDITION) |
165 mm (UNLADEN CONDITION) |
165 mm (UNLADEN CONDITION) |
| MINIMUM TRUNING RADIUS |
4.6m |
4.6m |
4.6m |
ENGINE
:
| SPECIFICATION |
LXi/ LXi CNG |
VXi/ VXi AGS |
VXi+/ VXi+ AGS |
| ENGINE TYPE |
ALL ALUMINIUM LIGHT WEIGHT K10B |
ALL ALUMINIUM LIGHT WEIGHT K10B |
ALL ALUMINIUM LIGHT WEIGHT K10B |
| SWEPT VOLUME |
998 cc |
998 cc |
998 cc |
| NUMBER OF CYLINDERS |
3 |
3 |
3 |
| NUMBER OF VALVES IN EACH CYLINDER |
4 |
4 |
4 |
| EMISSION |
BS IV + OBD-II COMPLIANT |
BS IV + OBD-II COMPLIANT |
BS IV + OBD-II COMPLIANT |
MAX ENGINE OUTPUT |
50.0 kW @ 6200 rpm (Petrol Mode - LXi / LXi CNG) |
50.0 kW @ 6200 rpm(VXi) |
50.0 kW @ 6200 rpm(Vxi+) |
| MAX ENGINE OUTPUT |
43.5 kW @ 6200 rpm (CNG Mode - LXi CNG only) |
50.0 kW @ 6000 rpm (VXi AGS) |
50.0 kW @ 6000 rpm (Vxi+ AGS) |
| MAX TORQUE |
90 Nm @ 3500 rpm (Petrol Mode - LXi / LXi CNG) |
90 Nm @ 3500 rpm |
90 Nm @ 3500 rpm |
| MAX TORQUE |
77 Nm @ 3500 rpm (CNG Mode - LXi CNG only) |
90 Nm @ 3500 rpm |
90 Nm @ 3500 rpm |
SUSPENSIONS
:
| SPECIFICATION |
LXi/ LXi CNG |
VXi/ VXi AGS |
VXi+/ VXi+ AGS |
| FRONT |
MCPHERSON STRUT WITH COIL SPRING |
MCPHERSON STRUT WITH COIL SPRING |
MCPHERSON STRUT WITH COIL SPRING |
| REAR |
ISOLATED TRAILING LINK WITH COIL SPRING |
ISOLATED TRAILING LINK WITH COIL SPRING |
ISOLATED TRAILING LINK WITH COIL SPRING |
CAPACITIES
:
| SPECIFICATION |
LXi/ LXi CNG |
VXi/ VXi AGS |
VXi+/ VXi+ AGS |
| SEATING CAPACITY |
5 |
5 |
5 |
| FUEL TANK CAPACITY |
"35 Litres (Petrol - LXi/LXi CNG)60 Litres (CNG cylinder water filling capacity - LXi CNG)" |
35 Litres |
35 Litres |
TYRES
:
| SPECIFICATION
|
LXi/ LXi CNG
|
VXi/ VXi AGS
|
VXi+/ VXi+ AGS
|
| SIZE
|
145/80R13
|
155/65R14
|
155/65R14
|
| TYPE
|
TUBELESS
|
TUBELESS
|
TUBELESS
|
BRAKES
:
| SPECIFICATION |
LXi/ LXi CNG |
VXi/ VXi AGS |
VXi+/ VXi+ AGS |
| FRONT |
VENTILATED DISC |
VENTILATED DISC |
VENTILATED DISC |
| REAR |
DRUM |
DRUM |
DRUM |
| SPECIFICATION |
LXi/ LXi CNG |
VXi/ VXi AGS |
VXi+/ VXi+ AGS |
| FRONT |
VENTILATED DISC |
VENTILATED DISC |
VENTILATED DISC |
| Gross Vehicle Weight (Kg) |
1350 |
1350 |
1350 |
| Kerb Weight (Kg) |
870 LXi |
885 VXi |
885 VXi+ |
| Kerb Weight (Kg) |
875 LXi(O) |
890 VXi(O) |
890 VXi+(O) |
| Kerb Weight (Kg) |
960 LXi CNG |
890 VXi AGS |
890 VXi+ AGS |
| Kerb Weight (Kg) |
965 LXi CNG(O) |
895 VXi AGS (O) |
895 VXi+ AGS (O) |
TRANSMISSION
:
| SPECIFICATION |
LXi/ LXi CNG |
VXi/ VXi AGS |
VXi+/ VXi+ AGS |
| TRANSMISSION |
MT |
MT (VXi) Auto Gear Shift w/ automatic & manual mode (VXi AGS) |
MT (VXi+) Auto Gear Shift w/ automatic & manual mode (VXi+ AGS) |
